Operations at San Diego International

Operations at San Diego International: Ahead of the NBAA Leadership Conference 2018 taking place in San Diego this February 26-28, here’s what operators need to know about San Diego International.

San Diego International

• IATA code: SAN
• ICAO code: KSAN
• Latitude / Longitude: N32-44.0/W117-11.4
• Mag Var: 11E
• Elevation: 17 FT
• Fuel type: AVGAS JET
• Time Zone: UTC – 8 hours

San Diego International Airport (also known as Lindbergh Field) is a public airport located three miles outside the city of San Diego, California, and 15 miles from the United States and Mexican border at Tijuana. It is the busiest single-runway commercial airport in the US, and the second in the world after London Gatwick.

Operational Information

• Aircraft with an MTOW of more than 100,309 lbs and/or registered to special interest countries (China, Cuba, Iran, North Korea, Russia, Sudan, and Syria) require TSA Waiver Authorization if flying domestic legs within the U.S. FAA Route Authorization for landing and overflying is also required for aircraft registered in special interest countries.
• TSA Waiver Authorization is not required for aircraft with MTOW of less than 100,309 lbs overflying the United States and departing and arriving at portal countries (Canada, Mexico, Bahamas, Bermuda, British Virgin Islands, & Cayman Islands). Aircraft registered in these countries are also authorized to operate within the Territorial Airspace of the U.S. so long as all applicable regulations are met.
• Non-scheduled commercial flights require U.S. Department of Transportation license to operate flights in the USA.
• Foreign operators wishing to provide air transportation services must obtain two authorizations from the Department of Transportation:

1. Economic Authority from the Office of the Secretary of Transportation in the form of a certificate for interstate or foreign passenger and/or cargo authority
2. Safety Authority in the form of an Air Carrier Certificate and Operations Specifications from the Federal Aviation Administration (FAA)

NOTAM

Restriction currently in please because of a nighttime runway closure:

02/106 (A0361/18) – RWY 09/27 CLSD MON-SAT 0800-1300. 20 FEB 08:00 2018 UNTIL 10 MAR 13:00 2018.

Airport Information

• TERRAIN & BLDGS TO 500′ MSL N & E WITHIN 1 1/2 MI.
• PRACTICE APPROACHES AND TGL PROHIBITED.
• TO REDUCE JET BLAST IMPACT AT N END OF TWY F ACFT WILL NOT START ENG UNTIL 800 FT FM N END OF TWY F; ABEAM THE SECOND PARKING PAD.
• ULTRALIGHT VEHICLES PROHIBITED ON ARPT.
• 747 AND LARGER ACFT ARE PROHIBITED FM MAKING INTERSECTION TKOFS.
• INTERMITTENT PRESENCE OF BIRDS ON AND INVOF OF ARPT.
• CROSS-BLEED ENGINE STARTS PERMITTED ONLY ON PARALLEL TWY WITH ACFT ALIGNED ON TWY CNTRLN.
• OUTBOARD ENGINES OF FOUR-ENGINE ACFT ARE TO BE KEPT AT IDLE POWER FOR ALL GND MANEUVERING.
• TAXIING ACFT ARE PROHIBITED FROM PASSING TO THE SOUTH OF ACFT LCTD ON TWY B INTO ALLEY LCTD BTWN GATES 7 AND 14. TAXIING ACFT SHALL FOLLOW LEAD-IN LINES UNTIL THE NOSE WHEEL OF THE ACFT HAS ENTERED THE NON-MOVEMENT AREA OF THE ALLEY.
• PILOTS REQUIRED TO CTC ATCT GROUND CONTROLLER PRIOR TO PUSHBACK, TOW OUT AND TAXI FOR TRAFFIC ADVISORIES.
• MILITARY ACFT ON OFFICIAL BUSINESS ONLY CONTACT ARPT OPS AT 619-400-2710 FOR PPR.
• ASDE-X IN USE. OPERATE TRANSPONDERS WITH ALTITUDE REPORTING MODE AND ADS-B (IF EQUIPPED) ENABLED ON ALL TWYS AND RWYS.
• TWY C EDGE LGTS OTS INDEFLY.
• ACFT CROSSING RY 09/27 ON TWY C6, HOLD SHORT OF TWY C6 FACING WEST ON TWY C, PARALLEL TO RY.
• DUE TO PAEW ON RY 09-27, 30 MINUTE PPR 0830-1230Z FOR ALL LANDINGS AND DEPARTURES CALL 619-400-2710.
• 30 MIN PPR (619-400-2710) FOR ACFT WITH OVER 171 FT WINGSPAN.
• IN THE EVENT OF A DIVERSION OR IRREGULAR OPERATIONS EVENTS, ACFT OPERATORS CONTACT THE APT DUTY MGR (619) 400-2710 FOR PPR DUE TO LIMITATIONS ASSOCIATED WITH HANDLING DIVERTED FLTS. LIMITATIONS INCLUDE RESTRICTED GATE SPACE, CUSTOMS SERVICES AS WELL AS ACFT SERVICING & PARKING.
• FOR ACCESS TO/FR TERMINAL 2: GATES 23, 25, 27, 29, 31, 33-51 AND THE ISLAND AND WEST RON PARKING RAMPS, CTC RAMP CONTROL ON 129.775 FR 0600-2400. FR 0000-0600 CTC GROUND CONTROL ON 123.9. TAXILANE A RSTRD TO ACFT WITH WINGSPANS OF 171 FT OR LESS. ACFT WITH WINGSPANS GREATER THAN 200 FT INBOUND TO WEST RAMP OR GATES 47 OR 51 MUST ACCESS VIA TCP #1.
• TWY B RSTD TO ACFT WITH WINGSPANS GREATER THAN 171 FT BTWN TWY B6 & TWY D.
• ACFT WITH WINGSPANS GREATER THAN 171 FT (52M) RSTD FROM USING TWY D SOUTH OF TWY B, AND WHEN EXITING RWY 9 WESTBOUND ON TWY B.

Visit San Diego International Airport’s official website for more information:  http://www.san.org/

For support with flight operations to San Diego International Airport, contact UAS Americas
